MSCN 2D Reversible | Dual-Terrain Multispectral Camouflage Net
Jetcord’s Ultralight Multi-Spectral Camouflage Net (2–100 GHz) represents the latest in advanced concealment technology, designed to protect military assets from detection across visual, infrared (IR), and radar (RF) spectrums. Engineered for full-spectrum stealth, this net offers effective camouflage from visible light, NIR, thermal imaging (MWIR & LWIR), and radar frequencies from 2 to 100 GHz covering threats from ground-based, aerial, and satellite surveillance. Crafted from ultralightweight composite materials, the net is modular, fire-resistant, UV-stabilized, and water-repellent, ensuring high performance and durability in extreme operational environments. Its reversible camouflage design enables quick adaptation between terrains such as Woodland/Desert or Forest/Snow, making it ideal for rapid deployment. Jetcord’s latest generation camouflage nets are tested to meet modern battlefield requirements, providing unmatched concealment, mobility, and survivability. This ultralight multi-spectral net is a strategic asset for forward-deployed units and high-value installations in need of adaptable, full-spectrum protection.
SPECIFICATIONS
- Colour: Woodland/Desert, Desert/Semi Desert, Forest/Semi Forest, Barren/Snow or customizable as required
- Construction: 2D single layer (Non incised)
- Visual Range: 380 nm to 750 nm
- NIR Range: 750 nm to 1200 nm
- TIR Range: 3000-5000nm & 8000-14000nm
- Thermal Transmission: Below 30%
- Thermal Loading: ±10°C
- Radar Range: 2-100 Ghz
- Radar Attenuation: Both way attenuation shall be 12db
- Shrinkage: Below 5%
- Tensile Strength: 30 kgs
- Tear Strength: 3 kgs
- Weight: Customized Or below 300 gsm
- Water Absorption: Below 30%
- Flame Resistant/Combustibility: Self Extinguishing within 15 seconds
- Wind Tolerance: Withstands high altitude and high wind speed up to 40 kmph
- Heat & Cold Resistance: -20°C to +70°C
- Anti Fungal/Micro organism Resistance: The fabric offers excellent antimicrobial resistance, effectively preventing the growth of fungi and microorganism
- Hydrocarbons Resistance: Excellent resistant to lube, oils and other hydrocarbons
- Joining: Capable of being joined together with ease to form a larger camouflage net
- Life of equipment: Shelf life: 7 years, Field life: 3 years or 150 handlings
- Finish: Matte finish to avoid reflections reaffirmed 2007 at 60 degree incident light < 5 GU
- Garnishing Fabric: Synthetic & Polymer coated
- Supporting Cordage: Synthetic
- Size of MSCN: Customized
