Anti-Thermal Camouflage Net | SPECIFICATIONS

Jetcord’s Anti-Thermal Camouflage Nets are high-performance concealment solutions designed to mask military vehicles, equipment, and personnel from detection across the full electromagnetic spectrum from visible light, near-infrared (NIR), and short-wave infrared (SWIR) to mid-wave infrared (MWIR: 3–5 µm) and long-wave infrared (LWIR: 8–14 µm). These nets are constructed using low-emissivity, heat-reflective materials that suppress thermal radiation, minimizing detection by drones, night vision optics, and heat-seeking systems.

Jetcord combines thermal masking with visual camouflage, offering lightweight, rugged nets that are also fire resistant, UV-stabilized, and water repellent ensuring durability and effectiveness in harsh operational conditions.

Optimized for diverse terrains, Jetcord’s nets are available in Woodland, Forest, Desert, Snow, and Barren Mountain patterns, or can be tailored to specific mission requirements. Extensively tested for thermal shielding and environmental endurance, these nets deliver multi-spectral concealment for superior stealth and survivability in the modern battlefield.

Specifications

• Colour: Woodland, Desert, Forest, Snow, and Barren Mountain, or customizable as required
• Construction: 3D double layer (incised Or Non Incised)
• 3D Cut Pattern: Customized
• Visual Range: 380 nm to 750 nm
• NIR Range: 750 nm to 1200 nm
• TIR Range: 3000-5000nm & 8000-14000nm
• Thermal Transmission: Below 30%
• Thermal Loading: ±10°C
• Shrinkage: Below 5%
• Tensile Strength: 30 kgs
• Tear Strength: 3 kgs
• Weight: Customized Or below 300 gsm
• Water Absorption: Below 30%
• Flame Resistant/Combustibility: Self Extinguishing within 15 seconds
• Wind Tolerance: Withstands high altitude and high wind speed up to 40 kmph
• Heat & Cold Resistance: -20°C to +70°C
• Anti Fungal/Micro organism Resistance: The fabric offers excellent antimicrobial resistance, effectively preventing the growth of fungi and microorganism
• Hydrocarbons Resistance: Excellent resistant to lube, oils and other hydrocarbons
• Joining: Capable of being joined together with ease to form a larger camouflage net
• Life of equipment: Shelf life: 7 years, Field life: 3 years or 150 handlings
• Finish: Matte finish to avoid reflections reaffirmed 2007 at 60 degree incident light < 5 GU
• Garnishing Fabric: Synthetic & Polymer coated
• Supporting Cordage: Synthetic
• Size of MSCN: Customized
